C
REATING
T
RUNK
G
ROUPS
8-17
Displaying LACP Port Counters
You can display statistics for LACP protocol messages.
Web – Click Port, LACP, Port Counters Information. Select a member
port to display the corresponding information.
Figure 8-6 LACP - Port Counters Information
Table 8-1 LACP Port Counters
Parameter Description
LACPDUs Sent Number of valid LACPDUs transmitted from this channel
group.
LACPDUs Received Number of valid LACPDUs received by this channel
group.
Marker Sent Number of valid Marker PDUs transmitted from this
channel group.
Marker Received Number of valid Marker PDUs received by this channel
group.
Marker Unknown
Pkts
Number of frames received that either (1) Carry the Slow
Protocols Ethernet Type value, but contain an unknown
PDU, or (2) are addressed to the Slow Protocols group
MAC Address, but do not carry the Slow Protocols
Ethernet Type.
Marker Illegal Pkts Number of frames that carry the Slow Protocols Ethernet
Type value, but contain a badly formed PDU or an illegal
value of Protocol Subtype.
