P
ORT
C
ONFIGURATION
8-16
CLI – The following example configures LACP parameters for ports 1-10.
Ports 1-8 are used as active members of the LAG, ports 9 and 10 are set to
backup mode.
Console(config)#interface ethernet 1/1 24-2
Console(config-if)#lacp actor system-priority 3 25-6
Console(config-if)#lacp actor admin-key 120 25-7
Console(config-if)#lacp actor port-priority 128 25-9
Console(config-if)#exit
.
.
.
Console(config)#interface ethernet 1/10
Console(config-if)#lacp actor system-priority 3
Console(config-if)#lacp actor admin-key 120
Console(config-if)#lacp actor port-priority 512
Console(config-if)#end
Console#show lacp sysid 25-10
Channel Group System Priority System MAC Address
-------------------------------------------------------------------
1 3 00-00-E9-31-31-31
2 32768 00-00-E9-31-31-31
3 32768 00-00-E9-31-31-31
.
.
.
Console#show lacp 1 internal 25-10
Port channel: 1
-------------------------------------------------------------------
Oper Key: 120
Admin Key: 0
Eth 1/ 1
-------------------------------------------------------------------
LACPDUs Internal: 30 sec
LACP System Priority: 3
LACP Port Priority: 128
Admin Key: 120
Oper Key: 120
Admin State: defaulted, aggregation, long timeout, LACP-activity
Oper State: distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
.
.
.
