S
PANNING
T
REE
C
OMMANDS
29-8
Related Commands
spanning-tree forward-time (29-5)
spanning-tree hello-time (29-6)
spanning-tree priority
This command configures the spanning tree priority globally for this
switch. Use the no form to restore the default.
Syntax
spanning-tree priority priority
no spanning-tree priority
priority - Priority of the bridge. (Range: 0 - 65535)
(Range – 0-61440, in steps of 4096; Options: 0, 4096,
8192, 12288, 16384, 20480, 24576, 28672, 32768, 36864,
40960, 45056, 49152, 53248, 57344, 61440)
Default Setting
32768
Command Mode
Global Configuration
Command Usage
Bridge priority is used in selecting the root device, root port, and
designated port. The device with the highest priority (i.e., lower
numeric value) becomes the STA root device. However, if all devices
have the same priority, the device with the lowest MAC address will
then become the root device.
Example
Console(config)#spanning-tree priority 40000
Console(config)#
