C REATING T RUNK G ROUPS
8-11
CLI – This example creates trunk 1 with ports 9 and 10. Just connect
these ports to two static trunk ports on another switch to form a trunk.
Enabling LACP on Selected Ports
Command Usage
• To avoid creating a loop in the network,
be sure you enable LACP before
connecting the ports, and also
disconnect the ports before disabling
LACP.
• If the target switch has also enabled
LACP on the connected ports, the trunk
will be activated automatically.
Console(config)#interface port-channel 1 24-2
Console(config-if)#exit
Console(config)#interface ethernet 1/9 24-2
Console(config-if)#channel-group 1 25-3
Console(config-if)#exit
Console(config)#interface ethernet 1/10
Console(config-if)#channel-group 1
Console(config-if)#end
Console#show interfaces status port-channel 1 24-12
Information of Trunk 1
Basic information:
Port type: 1000T
Mac address: 00-30-F1-D4-73-A2
Configuration:
Name:
Port admin: Up
Speed-duplex: Auto
Capabilities:
10half, 10full, 100half, 100full, 1000full
Flow control: Disabled
Port security: Disabled
Max MAC count: 0
Current status:
Created by: User
Link status: Up
Port operation status: Up
Operation speed-duplex: 1000full
Flow control type: None
Member Ports: Eth1/9, Eth1/10,
Console#
active
links
}
}
dynamically
enabled
configured
members
backup
link
