S PANNING T REE A LGORITHM
10-24
CLI – This example sets the priority for MSTI 1, and adds VLANs 1-5 to
this MSTI.
Displaying Interface Settings for MSTP
The MSTP Port Information and MSTP Trunk Information pages display
the current status of ports and trunks in the selected MST instance.
Field Attributes
MST Instance ID – Instance identifier to configure. (Range: 0-4094;
Default: 0)
Note: The other attributes are described under “Displaying Interface
Settings,” page 10-13.
Web – Click Spanning Tree, MSTP, Port Information or Trunk
Information. Select the required MST instance to display the current
spanning tree values.
Figure 10-6 MSTP Port Information
Console(config)#spanning-tree mst-configuration 29-10
Console(config-mst)#mst 1 priority 4096 29-12
Console(config-mstp)#mst 1 vlan 1-5 29-11
Console(config-mst)#
