SHOW

SNMP

GROUP

21-17

Group Name: public

Security Model: v2c

Read View: defaultview

Write View: none

Notify View: none

Storage Type: volatile

Row Status: active

Group Name: private

Security Model: v1

Read View: defaultview

Write View: defaultview

Notify View: none

Storage Type: volatile

Row Status: active

Group Name: private

Security Model: v2c

Read View: defaultview

Write View: defaultview

Notify View: none

Storage Type: volatile

Row Status: active

Console#

Table 21-4 show snmp group - display description

Field Description

groupname Name of an SNMP group.

security model The SNMP version.

readview The associated read view.

writeview The associated write view.

notifyview The associated notify view.

storage-type The storage type for this entry.

Row Status The row status of this entry.
