VLAN C
ONFIGURATION
11-6
Displaying Basic VLAN Information
The VLAN Basic Information page displays basic information on the
VLAN type supported by the switch.
Field Attributes
• VLAN Version Number
12
– The VLAN version used by this switch as
specified in the IEEE 802.1Q standard.
• Maximum VLAN ID – Maximum VLAN ID recognized by this
switch.
• Maximum Number of Supported VLANs – Maximum number of
VLANs that can be configured on this switch.
Web – Click VLAN, 802.1Q VLAN, Basic Information.
Figure 11-2 VLAN Basic Information
CLI – Enter the following command.
12. Web Only.
Console#show bridge-ext 30-3
Max support VLAN numbers: 256
Max support VLAN ID: 4093
Extended multicast filtering services: No
Static entry individual port: Yes
VLAN learning: IVL
Configurable PVID tagging: Yes
Local VLAN capable: No
Traffic classes: Enabled
Global GVRP status: Disabled
GMRP: Disabled
Console#
