Specifying Network Interfaces for RIP
You must specify network interfaces that will be included in the RIP
routing process.
Command Usage
• RIP only sends updates to interfaces specified by this command.
• Subnet addresses are interpreted as class A, B or C, based on the first
field in the specified address. In other words, if a subnet address
nnn.xxx.xxx.xxx is entered, the first field (nnn) determines the class:
0 - 127 is class A, and only the first field in the network address is used.
128 - 191 is class B, and the first two fields in the network address are
used.
192 - 223 is class C, and the first three fields in the network address are
used.
Command Attributes
• Subnet Address – IP address of a network directly connected to this
router.
Web - Click Routing Protocol, RIP, Network Addresses. Add all interfaces
that will participate in RIP, and click Apply.
Figure 17-15 RIP Network Addresses
