R

ATE

L

IMIT

C

OMMANDS

27-2

Default Setting

Gigabit Ethernet: 1000 Mbps

Command Mode

Interface Configuration (Ethernet, Port Channel)

Command Usage

Rate limits are not supported for the 10 Gigabit Ethernet ports.

Example

Console(config)#interface ethernet 1/1

Console(config-if)#rate-limit input 600

Console(config-if)#
