IGMP S

NOOPING

OMMANDS

33-5

Example

The following shows the current IGMP snooping configuration:

show mac-address-table multicast

This command shows known multicast addresses.

Syntax

show mac-address-table multicast [vlan vlan-id]

[user | igmp-snooping]

• vlan-id - VLAN ID (1 to 4093)

• user - Display only the user-configured multicast entries.

• igmp-snooping - Display only entries learned through IGMP

snooping.

Default Setting

None

Command Mode

Privileged Exec

Command Usage

Member types displayed include IGMP or USER, depending on

selected options.

Console#show ip igmp snooping

Service status: Enabled

Querier status: Disabled

Query count: 2

Query interval: 125 sec

Query max response time: 10 sec

Router port expire time: 300 sec

IGMP snooping version: Version 2

Console#
