IP R

OUTING

17-18

CLI - This example provides detailed statistics on common IP-related

protocols.

Console#show ip traffic 37-7

IP statistics:

Rcvd: 5 total, 5 local destination

0 checksum errors

0 unknown protocol, 0 not a gateway

Frags: 0 reassembled, 0 timeouts

0 fragmented, 0 couldn't fragment

Sent: 9 generated

0 no route

ICMP statistics:

Rcvd: 0 checksum errors, 0 redirects, 0 unreachable, 0 echo

5 echo reply, 0 mask requests, 0 mask replies, 0 quench

0 parameter, 0 timestamp

Sent: 0 redirects, 0 unreachable, 0 echo, 0 echo reply

0 mask requests, 0 mask replies, 0 quench, 0 timestamp

0 time exceeded, 0 parameter problem

UDP statistics:

Rcvd: 0 total, 0 checksum errors, 0 no port

Sent: 0 total

TCP statistics:

Rcvd: 0 total, 0 checksum errors

Sent: 0 total

ARP statistics:

Rcvd: 0 requests, 1 replies

Sent: 1 requests, 0 replies

Console#
