B
ASIC
IP C
ONFIGURATION
36-21
Example
This example assigns a link-local address of FE80::269:3EF9:FE19:6779 to
VLAN 1. Note that the prefix FE80 is required for link-local addresses,
and the first 16-bit group in the host address is padded with a zero in the
form 0269.
Related Commands
ipv6 enable (36-10)
show ipv6 interface (36-22)
Console(config)#interface vlan 1
Console(config-if)#ipv6 address 2001:0DB8:0:1::/64 eui-64
Console(config-if)#end
Console#show ipv6 interface
Vlan 1 is up
IPv6 is enable.
Link-local address:
FE80::269:3EF9:FE19:6779/64
Global unicast address(es):
2001:DB8::1:200:E8FF:FE90:0, subnet is 2001:DB8:0:1::/64
Joined group address(es):
FF01::1/16
FF02::1/16
FF02::1:FF19:6779/104
MTU is 1500 bytes.
ND DAD is enabled, number of DAD attempts: 1.
ND retransmit interval is 1000 milliseconds
Console#
