Vista Digital Mixing System
2-10 Desk Operation SW V3.3 Date printed: 05.08.03
[33] ¹ VIEW: CHANNEL
Brings up a view of all control elements of this channel besides dynamics,
equalizer, and pan, covering the whole Vistonics™ rotary control area.
[34]
¹ VIEW: MISC – View Selection of DYNAMICS, EQ, and PAN Con-
trols
Brings up a view of selected control elements out of dynamics, equalizer,
and pan, covering the whole Vistonics™ rotary control area. The VIEW
CHANNEL [33] and VIEW MISC [34] keys form a sort of “center assign
panel” function, known from many other consoles, such as the Studer
D950 M2.
[35]
¹ VIEW: BUS ASN
Brings up the bus assign view of one channel, covering the whole touch
screen area.
When showing the bus assignment of a single channel, the assignment can
be changed by touching the bus number. It is also possible to clear all bus
assignments of a type by pressing the corresponding key on the touch
screen.
[36] GLOBAL VIEW: LABEL TYPE
Changes the label type of the second line in the generic display area [32] to
show:
• Inherited label (also known as source label)
• Fixed label (shows the channel number)
• User label (usually equals the Device label)
[37]
¹ GLOBAL VIEW: BUS ASN
Activates a “bubble view” of the bus assignment throughout the whole
console. If the bay is locked, only the corresponding bay is affected.
