Engineer programming via the keypad
X-BUS
126
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
Editing Keyswitch Expanders
The following table lists the available options for keyswitch expanders:
Name
Description
DESCRIPTION
Enter or edit a description for the expander.
LOCATION
Select a location for the expander from the list of defined areas.
LATCH
Enable or disable the latch on the key position.
VISUAL INDICATIONS
(Flexible mode only)
Enables you to assign specific behaviour to each LED on the
keyswitch expander. Each of the LEDs has the following
options:
 FUNCTION — the following options are available:
– KEYSWITCH — select a keyswitch and the position of
the key.
– DISABLED — select to disable the LED.
– SYSTEM — select the alarm type which triggers the
LED.
– AREA — select the area which triggers the LED.
– ZONE — select the zone which triggers the LED
– DOOR — select the door and the door option which
triggers the LED.
 ON – COLOR — specify the activation colour
 ON – FLASH — specify the behaviour of the LED in active
state. Available options are:
– Permanent — always on.
– Flash Fast\Medium\Slow — varying speed of the
flashing.
 OFF – COLOR — specify the deactivation colour.
 OFF – FLASH — specify the behaviour of the LED in the
inactive state. Available options are:
– Permanent — always on.
 Flash Fast\Medium\Slow — varying speed of the flashing.
DEACTIVATION
(Flexible mode only)
Select a deactivation method from the available options:
 Calendar — select a calendar.
KEY POSITIONS
Enables you to assign behaviour to specific key positions for
specific areas.
Select an area for the key position, and assign one of the
following options to that area:
 None
 Unset
 Partset A
 Partset B
 Fullset
 Toggle Unset/Fullset
 Toggle Unset/Partset A
 Toggle Unset/Partset B
 All Okay
 Setting Authorisation
16.6.4.4.6
