Restriction
System Option
Description
Web and
SPC Pro
Only
Audio Expander
LED
If enabled, audio expander will not turn on LED when
microphone active.
Report in Eng
mode
If enabled, the panel will always report alarm activations
and panic alarms.
Outputs in Eng
Mode
If selected, the following are not deactivated in Full
Engineer mode:
 Controller outputs
 Expander outputs
 Indicator LEDs
 Keyswitch LEDs
Alarm on
Reporting Fail
If a ‘Fail to Communicate‘ alert is raised, external bells
will activate.
Retrigger Duress
If enabled, duress alarm will retrigger.
Retrigger Panic
If enabled, panic alarm will retrigger.
Override Reader
Profile
If enabled, the LED behavior of readers will be controlled
by the panel.
Silence Audio
Verification
If enabled, then the internal and external bells (system
and area), the keypad buzzers and annunciation
messages on the Comfort Keypad will be silenced during
audio verification.
Watchdog Output
Mode
Enables output 6 on the SPC controller board to be used
for monitoring purposes. The following modes of
operation of the watchdog output can be selected:
 Disable — Output 6 is available as a general purpose
output.
 Enabled — Output 6 is normally OFF but is turned
ON when a watchdog fault occurs.
 Pulsed — Output 6 is PULSED at 100ms intervals.
 Enabled Inverted — Output 6 is normally ON but is
turned OFF when a watchdog fault occurs.
The following options combine the Enabled option with
hardware-fault reporting in the event of a main
microprocessor failure. If such a failure occurs, a SIA
event is sent to ARC1.
Note: The ARC must be configured to use SIA and SIA
Extended 1 or 2. CID and FF are not supported by this
reporting method.
 Enabled + Reporting (10s) — The failure event is
sent to ARC1 10 seconds after the fault is detected.
This option must be used to comply with VdS 2252.
 Enabled +Reporting (60s) — The failure event is sent
to ARC1 60 seconds after the fault is detected.
The SIA event reported is HF and Extended SIA reports
Hardware Fault.
Note: Hardware faults are not reported if the Engineer is
logged in to the system.
For more information on ARCs, see Alarm Reporting
Centres (ARCs) [➙ 292].
SPCP355
Enable VDS power supply.
For VdS installations, this option is automatically
selected.
Bell on Fail to Set
(FTS)
Enable to activate the internal bell if the system fails to
set.
Strobe on Fail to
Enable to activate the strobe if the system fails to set.
