Vanderbilt SPC53 Series User Manual

Engineer programming via the browser
17
Configuration
239
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
4. Enter a description for the new area and select an area type from one of the
following:
- Standard - Suitable for most areas.
- ATM - Provides settings and defaults relevant to ATMs.
- Vault - Provides settings and defaults relevant to vaults.
- Advanced – Provides all area settings (Standard, ATM and Vault).
5. Click on the Add button to add the area.
 Configure the settings for each installation type as per the following sections:
Entry/Exit
Configure the following Entry/Exit settings:
Entry time
The time period (in seconds) allowed for the user to UNSET the alarm
after opening an entry/exit zone of an armed system. The entry time
applies to all entry/exit zones in that area (default: 45 seconds).
Exit time
The time (in seconds) allowed for a user to leave a protected area
before setting is complete. The exit time will be counted down at the
keypad as the buzzer beeps to indicate to the user that the system will
arm when the exit timer reaches zero. The exit time applies to all
entry/exit zones in that area (default: 45 seconds).
Disable Exit Time
Select if no exit timer is required and setting is activated by ‘Exit term’
zone or ‘Entry exit’ zone with ‘Final exit’ attribute. See Timers [➙ 230].
Fob Unset Entry
FOB will only unset when entry timer is running. Default is enabled.
Access Denied on Alarm
Access is temporarily denied to the area for the amount of time
specified in the Lockout Post Alarm timer.
Prevent Setting
If enabled, setting prevented from keypad
Prevent Unsetting
If enabled, unsetting prevented from the keypad.
Setting Authorisation
Used for configuring Blocking Lock operation. Options are:
 Disabled
 Set
 Unset
 Set and Unset
If the Disabled option is selected (default) then the system will set and
unset normally with no change of operation.
If the Set option is selected, a “Setting Authorisation” signal is required
to set this area which can be received from keypads or a zone input
(see Authorised Setting of the Blocking Lock) The user cannot set the
system from the keypad. Any area that requires setting authorisation
will appear as locked on the comfort keypad and will not appear on the
standard keypad when setting.
If the Unset option is selected, the user cannot unset the area from
keypads but can use the keypad to generate the setting authorization
signal.
For the set and unset options, the user will be unable to change the
state of the area at any stage from the keypad.
A timer for setting authorisation can be configured. See Timers [➙ 230].
Partset Options
17.9.5.2.1
17.9.5.2.2
