Engineer programming via the browser
Installation & Configuration Manual
The area the zone and the card reader are assigned to.
(If the card reader is used for setting & unsetting, this
area will be set / unset).
DPS End Of Line (keypads)
Door Position EOL (SPC Pro)
The resistor used with the door position sensor. Choose
the used resistor value / combination.
Select if the door release switch is to be a normally open
or normally closed input.
DRS END OF LINE (Keypads)
Door Position EOL (SPC Pro)
The resistor used with the door release switch. Choose
the used resistor value / combination.
Select if the door release switch is a normally open input
or not.
If a DC2 is used on the door, this option MUST be
selected. If not selected, the door will open.
Reader Location (Entry/Exit)
Select the location of the entry and exit readers.
Displays format of last card used with each configured
reader. (not available in SPC Pro)
Each free zone number can be assigned to the zones but the assignment is not
fixed. If the number ‘9’ is assigned to a zone, the zone and an input expander with
the address ‘1’ is connected to the X-Bus (which is using the zone numbers 9-16).
The assigned zone from the two door controller will be moved to the next free
zone number. Configuration will be adapted accordingly.
Door attributes
If no attribute is activated, a valid card can be used.
The card is temporarily blocked.
Used when multiple doors are assigned to the same
area and/or anti passback, custodian, or interlock
functionality is required.
Card and PIN are required to gain entry.
PIN is required. No card will be accepted.
PIN or card are required to gain entry
PIN is required on exit reader. Door with entry and
exit reader is required.
PIN is required to set and unset the linked area. The
card has to be presented before the PIN is entered.
Unset on Entry Reader (SPCPro)
Panel/area will unset, when card is presented at entry
reader.
