Page #208 background imageLoading...
Page #208 background image
10/00
2-194
Phaser 790/DocuColor 2006
011-701
Initial Issue
Status Indicator RAPs
There is +5 VDC between P 10-3 and GND.
YN
Go to Flag 7. Check for an open circuit. The wire is good.
YN
Repair the wire.
Go to Flag 8. Check for an open circuit. The wires are good.
YN
Repair the wires.
Replace the Sorter Control PWB (PL 19.1).
Replace the Sensor Receiver (PL 19.2).
Replace the Sorter Control PWB (PL 19.1).
Remove the paper in Bin 1. Access the Digital Output (DO) test from the Control Panel. Enter
code [D6]. Press the Item/Enter button. The display is 0.
YN
Replace the Sensor Receiver (PL 19.2).
Replace the Sorter Control PWB (PL 19.1).
B C D
