10/00
2-25
Phaser 790/DocuColor 2006
001-711
Status Indicator RAPs
Initial Issue
001-711 Area 6 Open RAP
The Control Logic has detected that area 6 is open.
Initial Actions
Perform the following:
• Ensure that the Inverter Chute (PL 15.5) is fully closed.
• Ensure that the actuator for the CAB Interlock is not broken. Repair any obvious defects.
Procedure
Access the Digital Input (DI) test from the Control Panel. Enter code [93]. Press the Item/Enter
button. The display indicates 0.
YN
Go to Flag 1 and Flag 2. Check the wires for a open circuit. If the wires are good, replace
the Duplex Controller PWB (PL 15.6).
The problem may be intermittent. Go to Flag 1 and Flag 2 and check for loose or damaged
connections or damaged wires. If the problem persists, replace the replace the Duplex Control-
ler PWB (PL 15.6).
To Next Page
