Phaser 790/DocuColor 2006
IOT Specifications, ADF Specifications
General Procedures and Information
3. Low Speed Mode: Prints at low speed when printing color on transparencies. This mode
is also used to enhance the glossy touch of heavy weight paper.
The following table shows the prints per minute generated with the associated paper types and
sizes.
First Print Out Time (FPOT)
With the machine in Ready mode, the time from the print designation from the driver on the PC
until the trail edge of the first sheet exits the IOT is shown as follows:
Image Loss
Following are the image loss specifications.
ADF Specifications
ADF Physical Characteristics
ADF Electrical Specifications
Frequency
• 50/60 Hz
±2%
Input Voltage
• +5 VDC and +24 VDC supplied by IOT.
Power Consumption
• 120 Watts
ADF System Capability
Document Size
• Maximum 11 x 17 (A3)
• Minimum 5.5 x 8.5 (A5)
• The ADF recognizes standard document sizes as shown Table 2 and Table 3.
Table 8 Prints Per Minute
Sheet Type Size Black & White Color
Plain paper 8.5 x 11 inch (A4)
8.5 x 14 inch (B4)
26 ppm 6 ppm
Plain paper 11 x 17 inch (A3) 13.8 ppm 3 ppm
Transparency or
thick paper
8.5 x 11 inch (A4)
8.5 x 14 inch (B4)
4.8 ppm 1.3 ppm
Table 9 First Print Out Time (FPOT)
Output Tray Print Mode FPOT
Face Up B/W prints Approximately 10.9 seconds
Face Up Color prints Approximately 25.9 seconds
Face Down B/W prints Approximately 13.9 seconds
Face Down Color prints Approximately 28.9 seconds
Table 10 Image Loss Specifications
Copy Portion Specification
Top Edge 4.0 mm or less
Right Edge 4.0 mm or less
Left Edge 4.0 mm or less
Bottom Edge 4.0 mm or less
Table 1 ADF Dimensions and Weights
Dimension US Metric
Width 24" 640 mm
Depth 20.5" 535 mm
Height 9" 130 mm
Weight: ADF only 31 lb. 14 kg
Table 2 ADF Size Sensing - (NASG)
Document Size (+/- 4 mm) Sensed Size
11
×17 11×17 (280×432)
11
×14.9 SEF 11×17 (280×432)
8.5
×14 SEF 8.5×14 (216×356)
8.5
×13 SEF 8.5×14 (216×356)
8.5
×12.4 SEF --
8.5
×11 SEF 8.5×11 (216×280)
8.5
×11 LEF 11×8.5 (280×216)
8
×10 SEF 8×11 (216×280)
8
×10 LEF 11×8.5 (280×216)
8.5
×5.5 SEF 5.5×8.5 (140×216)
8.5
×5.5 LEF 8.5×5.5 (216×140)
A4 SEF A4 (210
×297)
A4 LEF A4 (297
×210)
