10/00
4-145
Phaser 790/DocuColor 2006
REP 14.9, REP 14.10
Repairs and Adjustments
Initial Issue
REP 14.9 Right Cover
Parts List on PL 1.2
Removal
WARNING
To avoid personal injury or shock, do not perform repair activities with the power switch
on or electrical power applied to the machine.
1. Switch off the machine power and disconnect the machine Power Cord.
2. Open the Front Cover Assembly.
3. Remove the Right Cover (Figure 1).
Replacement
1. Align the hooks of the Right Cover with the holes on the back of the printer.
2. Reinstall the Right Cover in the reverse order of removal.
Figure 1 Removing the Right Cover
REP 14.10 Control Panel
Parts List on PL 1.2
Removal
WARNING
To avoid personal injury or shock, do not perform repair activities with the power switch
on or electrical power applied to the machine.
1. Switch off the machine power and disconnect the machine Power Cord.
2. Remove the Top Cover Assembly together with the Control Panel (REP 14.4).
CAUTION
Be careful not to damage the hooks of the Control Panel during the removal.
3. Remove the Control Panel (Figure 1).
Replacement
1. Reinstall the Control Panel in the reverse order of removal.
Figure 1 Removing the Control Panel
1
Remove the
three screws
2
Move the cover towards
the rear and remove the
Right Cover
1
Compress the
hooks to disengage
the Control Panel
2
Remove the
Control Panel
