03/01
6-31
Phaser 790/DocuColor 2006
Common Tools, Product Tools and Test Patterns
General Procedures and Information
Common Tools
The following table lists the common tools required for servicing the DC 2006 and Phaser 790.
Product Tools and Test Patterns
The following table lists the product specific tools and test patterns required for use in servicing
the DC 2006 and Phaser 790.
Table 1 Common Tools
Description Part Number
Digital Multimeter (DMM) 600T02020
DMM Lead Kit 600T02030
ESD Kit 600T42001
Diagonal Pliers 600T40903
Mini-Flashlight 600T01824
Ergonomic Tool 600T02123
2mm Hex Wrench 600T41102
Needle-Nose Pliers 600T40901
Long, assorted shim stock 600T41511
Brush 600T41901
150mm Ruler 600T41503
Table 1
Description Part Number
Color Test Pattern 082E13030
Copier Set-up Test Pattern 082E8220
Serial Cable 600T02058
Parallel Cable 600T02065
PWS AC Adapter Power Cord 600T02018
