10/00
2-23
Phaser 790/DocuColor 2006
001-710
Status Indicator RAPs
Initial Issue
001-710 Area 5 Open RAP
The Control Logic detected that the Fuser Drawer in not fully closed.
Initial Actions
Perform the following:
• Ensure that the Fuser Assembly is fully closed.
• Ensure that the Fuser Assembly is mounted correctly and securely. Repair any obvious
defects.
Procedure
Access the Digital Input (DI) test from the Control Panel. Enter code [62]. Press the Item/Enter
button. The display indicates 0.
YN
Go to Flag 1 and check the wire for a open circuit. If the wire is good, replace the MCU
PWB (PL 11.2).
The problem may be intermittent. Go to Flag 1 and check for loose or damaged connections or
damaged wires. If the problem persists, replace the MCU PWB (PL 11.2).
To Next Page
