10/00
5-78
Phaser 790/DocuColor 2006
PL 19.1
Initial Issue
Parts List
PL 19.1 Sorter Cover, Control PWB
Item Part Description
1 802K18200 Front Cover Assembly
2 – Front Cover (P/O PL 19.1 Item 1)
3 – Label (P/O PL 19.1 Item 1)
4 802E13310 Rear Cover
5 – Serial Number Plate (Not Spared)
6 802E13320 Top Cover
7 – Bearing (Not Spared)
8 110K10740 Sorter Top Cover Interlock
9 – Plate Spring (Not Spared)
10 – Harness (Not Spared)
11 160K68052 Sorter Control PWB (REP 11.3)
12 162K63040 Harness Assembly (Not Spared)
13 – Plate (Not Spared)
14 – Harness (Not Spared)
15 – Front Frame (Not Spared)
16 – Rear Frame (Not Spared)
17 – Sorter Assembly (Not Spared)
(REP 11.1)
To Next Page
