Xerox Phaser 790 User Manual

10/00
2-21
Phaser 790/DocuColor 2006
001-709
Status Indicator RAPs
Initial Issue
001-709 Area 4 Open RAP
Initial Actions
Perform the following:
• Check the actuator for the Exit Chute Interlock. Ensure it is not broken or damaged.
• Ensure the Exit Chute is closed.
Procedure
Access the Digital Input (DI) test from the Control Panel. Enter code [74]. Press the Item/Enter
button. The display indicates 0.
YN
Go to Flag 1 and Flag 2. Check the wires for an open circuit. If the wires are good, replace
the Exit Chute Interlock (PL 9.2). If the problem continues, replace the MCU PWB (PL
11.2).
The problem may be intermittent. Go to Flag 1 and Flag 2 and check for loose or damaged
connections or damaged wires. If the problem persists, replace the Exit Chute Interlock (PL
9.2). If the problem continues, replace the MCU PWB (PL 11.2).
