10/00
2-200
Phaser 790/DocuColor 2006
011-704
Initial Issue
Status Indicator RAPs
011-704 Sorter Noise RAP
There is noise emanating from the Sorter at power up.
Procedure
There is +5 VDC between J 8-10 of the Sorter Control PWB and GND.
YN
There is +5 VDC between J35-4 of the Low Voltage Power Supply and GND.
YN
Replace the LVPS (PL 11.1).
Go to Flag 1. Check for an open circuit.
Replace the Sorter Control PWB (PL 19.1).
To Next Page
