03/01
6-26
Phaser 790/DocuColor 2006
IOT Specifications
General Procedures and Information
Machine Power Consumption
The power consumption of the print engine, including the 500 sheet feeder and Duplex Tray, at
the rated voltage in each operating mode is as follows.
Environmental Specifications
Audible Noise
Ozone Generation
• Maximum 0.01 ppm (time weighted average)
Operating Range - Temp & RH
Temperature
• 50
°F (10°C) to 95°F (35°C)
Relative Humidity
• 15% TO 85% (No condensation)
Altitude
• 0-10,000 ft. (3100 m)
Levelness
• Maximum level difference - 5 mm or less (front to back)
• Maximum level difference - 10 mm or less (right to left)
Warm-up Time
• 100V: 8 minutes 45 seconds or less (20°(C) 68°(F), 60%)
• 110V: 8 minutes 45 seconds or less (20
°(C) 68°(F), 60%)
• 220V: 8 minutes 30 seconds or less (20
°(C) 68°(F), 60%)
Paper Supply Specifications
Copy Paper Weight Capability)
• Tray 1 - 16 lb./64 gsm through 28 lb./105 gsm
• Trays 2, 3 - 16 lb./64 gsm through 28 lb./105 gsm
• Bypass Tray - 16 lb./64 gsm through 120 lb. (index) /220 gsm
Paper Tray Capacity (20 lb./80 gsm)
• Tray 1 250 sheets
• Trays 2, 3 500 sheets
• Bypass Tray 150 sheets
Paper Cassette Type
Paper sizes and orientation loadable in each tray are as follows:
Printer Speed
There are three speed modes that the print engine considers for fusing speed in printing on dif-
ferent paper types. The speed mode is determined by the controller according to print mode
and paper type instructions from the ESS.
1. Standard Mode: Prints at the maximum speed of the machine.
2. Medium Speed Mode: Prints at medium speed to ensure the correct fusing on heavy
weight papers (greater than 28 lb. or 105 gsm) and black and white transparencies. This
mode is also used to enhance the glossy touch of plain paper.
Table 4 Power Consumption
Mode Watt Hours Fuser On Fuser Off
Running (color) 600 or less 1200 watts n/a
Running (b/w) 960 or less 1220 watts n/a
Ready 250 or less 1100 watts 100 watts
Save 200 or less 1100 watts 100 watts
Sleep 60 or less n/a 60 watts
Table 5 Audible Noise
Continuous Noise Impulse Noise
Stand by 57 db n/a
Copy Cycle 72 db 77 db
Table 6 Recognized Paper Sizes
NASG ESG
8
×10 LEF A4 LEF
A4 LEF 215
×279 LEF
8.5
×11 LEF A3 SEF
A3 SEF 215
×279 SEF
8.5
×11 SEF B4 ISO SEF
9
×12 SEF 215×315 SEF
8.5
×13 SEF 215×330 SEF
8.5
×14 SEF 215×356 SEF
A4 SEF A4 SEF
11
×17 SEF 279×432 SEF
Table 7 Recommended Paper
Mode NASG Market ESG Market
For B/W 4024DP (20#) 80 gsm Premier
3R91720,
3R91721
For Color Color Xpressions
93 (24# bond)
3R5464,
3R5465
Colortech Plus
(90 gsm)
3R94641 (A4),
3R94642 (A3)
