Xerox Phaser 790 User Manual

03/01
6-28
Phaser 790/DocuColor 2006
ADF Specifications, IIT (Scanner) Specifications
General Procedures and Information
Document Weight
• Document Tray Capacity 50 documents 38 - 100 gsm
40 documents 101 - 138 gsm
(Duplex: 50 gsm - 110 gsm)
Size Mixed Mode
• In this mode sizes from 5.5
×8.5 (A5) to 11×17 (A3) can be mixed.
Registration
• Lead edge
±2.5 mm
• Side edge
±3 mm
• Skew
±2.5 mm
IIT (Scanner) Specifications
Following are the Scanner specifications.
Magnification
R/E Factors
Magnification is variable in 1% increments from 25% to 400%. Six preset R/E factors are also
available. the following table shows the preset R/E factors available:
The following table indicates the R/E factors to use when enlarging or reducing from a specific
size document to a specific size copy.
Table 3 ADF Size Sensing - (ESG)
Document Size (+/- 4 mm) Sensed Size
11
×14.9 SEF 11×17 (280×432)
8.5
×14 SEF 8.5×14 (216×356)
8.5
×13 SEF 8.5×14 (216×356)
8.5
×12.4 SEF --
A3 A3 (297
×420)
B4 SEF B4 (257
×364)
A4 SEF A4 (210
×297)
A4 LEF A4 (297
×210)
B5 SEF B5 (182
×257)
B5 LEF B5 (257
×182)
A5 SEF A5 (148
×210)
A5 LEF A5 (210
×148)
Table 1 R/E Presets
NASG ESG
64% 70%
78% 81%
100% 86%
129% 100%
154% 115%
200% 141%
Table 2 Common R/E Factors
R/E value
Original size
→Copy
Size
35 A3
→A6
50 A3
→A5
64 11 x 17
→8.5 x 11
70 A3
→A4, B4→B5
78 8.5 x 14
→8.5 x 11
81 B4
→A4, B5→A5
86 A4
→B5, A3→B4
97 A4
→8.5 x 11
115 B5
→A4, B4→A3
122 A4
→B4, A5→B5
127 8.5 x 13
→A3
129 8.5 x 11
→11 x 17
141 A4
→A3, B5→B4
154 5.5 x 8.5
→8.5 x 14
180 8.5 x 13
→A2
200 A5
→A3
220 5.5 x 8.5
→11 x 17
282 A6
→A3
