Xerox Phaser 790 User Manual

03/01
6-29
Phaser 790/DocuColor 2006
IIT (Scanner) Specifications
General Procedures and Information
Magnification Accuracy
The magnification specifications and associated image distortion for Copy mode are shown in
the following table.
Platen Mode Size Detection
The IIT recognizes the following standard document sizes in Platen mode.
NOTE:
¹ Mix Mode only
² Default is A6S, Postcard S is selectable.
³ Default is Postcard S; A6 S is selectable.
Scanner Alignment
Following are the scanner alignment specifications.
First Copy Output Time (FCOT)
Parameters - AE Off, ACS Off, A4 SEF, Tray 1
• Black/White: 11.5 sec. or less
• Full color: 25.6 sec. or less
Table 3 Scanner Magnification Specification
Magnification Specification
25 - 49.9% +/- 1.0%
50 - 99.9% +/- 1.0%
100% +/- 1.0%
100.1 - 200% +/- 1.5%
200.1 - 400% +/- 2.2%
Table 4 Platen Mode Document Sizes
Document
orientation
Document
size (mm) NASG ESG
Postcard SEF 100 x 148 - -
(Post Card) (101 x 152) x ALT ²
A6 SEF 105 x 148 ALT ³ x
B6 SEF 128 x 182 x x
B6 LEF 182 x 128 - -
A5 SEF 148 x 210 x x
A5 LEF 210 x 148 x x
5.5 x 8.5 SEF 140 x 215.9 x x
5.5 x 8.5 LEF 215.9 x 140 x x
B5 SEF 215.9 x
279.4
x x
B5 LEF 279.4 x
215.9
x x
8.5 x 13 SEF 215.9 x
330.2
- x
8.5 x 14 SEF 215.9 x
355.6
x -
B4 SEF 257 x 364 x x
8th Opening SEF 267 x 388 x x
A3 SEF 297 x 420 x x
11 x 17 SEF 297.4 x
431.8
x x
Table 5 Reg/Skew Specifications
Item Application Specification
Registration Lead Edge +/- 0.5 mm
Registration Side Edge +/- 0.5 mm
Skew Lead Edge +/- 0.7 mm / 200
Skew Side Edge +/- 1.4 mm / 390
Linearity (fast scan) n/a +/- 1.0 mm / 200
Linearity (slow scan) n/a +/- 0.4 mm
