YASKAWA GA700 Series

Electrical Installation
3
3.15 Protect the Drive during Failures
YASKAWA SIEPC71061705H GA700 Series Technical Manual 127
Drive Model
Maximum Applicable Motor
Output
kW (HP)
Input Voltage < 460 V
Maximum Applicable Motor
Output
kW (HP)
Input Voltage ≥ 460 V
Input Current Rating
A
Semiconductor Protection
Fuse Rated Current
Manufacturer: EATON/
Bussmann
4103 55 (75) 55 (75) 105 FWH-275A
4140 75 (100) 75 (100) 142 FWH-300A
4168 90 (125) 90 (125) 170
FWH-325A
FWH-400A
*1
4208 110 (150) 110 (150) 207 FWH-500A
4250 132 (175) 150 (200) 248 FWH-600A
4296 160 (200) 185 (250) 300 FWH-700A
4371 200 (250) 220 (300) 373 FWH-800A
4389 220 (300) 260 (350) 410 FWH-1000B
4453 250 (335) 300 (400) 465 FWH-1200B
4568 315 (400) 335 (450) 584 FWH-1200B
4675 355 (450) 370 (500) 657 FWH-1400A
*1 Yaskawa recommends a fuse with a large rated current for applications with repeated loads.
Table 3.22 Factory-Recommended Branch Circuit Protection: 400 V Class (HD)
Drive Model
Maximum Applicable Motor
Output
kW (HP)
Input Voltage < 460 V
Maximum Applicable Motor
Output
kW (HP)
Input Voltage ≥ 460 V
Input Current Rating
A
Semiconductor Protection
Fuse Rated Current
Manufacturer: EATON/
Bussmann
4002 0.55 (0.75) 0.55 (0.75) 1.9 FWH-50B
4004 1.1 (1.5) 0.75 (1) 3.5 FWH-50B
4005 1.5 (2) 1.5 (2) 4.7 FWH-50B
4007 2.2 (3) 2.2 (3) 6.7 FWH-60B
4009 3 (4) 3 (4) 8.9 FWH-60B
4012 4.0 (5) 3.7 (5) 11.7 FWH-60B
4018 5.5 (7.5) 5.5 (7.5) 15.8 FWH-80B
4023 7.5 (10) 7.5 (10) 21.2 FWH-90B
4031 11 (15) 11 (15) 30.6 FWH-150B
4038 15 (20) 15 (20) 41.3 FWH-200B
4044 18.5 (25) 18.5 (25) 50.5 FWH-200B
4060 22 (30) 22 (30) 43.1 FWH-225A
4075 30 (40) 30 (40) 58.3 FWH-250A
4089 37 (50) 37 (50) 71.5 FWH-275A
4103 45 (60) 45 (60) 86.5 FWH-275A
4140 55 (75) 55 (75) 105 FWH-300A
4168 75 (100) 75 (100) 142
FWH-325A
FWH-400A
*1
4208 90 (125) 90 (125) 170 FWH-500A
4250 110 (150) 110 (150) 207 FWH-600A
4296 132 (175) 150 (200) 248 FWH-700A
4371 160 (200) 185 (250) 300 FWH-800A
4389 200 (250) 220 (300) 373 FWH-1000B
4453 220 (300) 260 (350) 410 FWH-1200B
4568 250 (335) 300 (400) 465 FWH-1200B
4675 315 (400) 335 (450) 584 FWH-1400A
*1 Yaskawa recommends a fuse with a large rated current for applications with repeated loads.
