YASKAWA GA700 Series

5.2 European Standards
240 YASKAWA SIEPC71061705H GA700 Series Technical Manual
Model EMC Noise Filter Model Qty Manufacturer
4568A FS5972-600-99 1 Schaffner
4675A FS5972-410-99 2 Schaffner
■ DC Reactor
To comply with IEC/EN 61000-3-2, install a DC reactor to drive models 2004, 2006, 4002, and 4004 when using
an internal or external EMC filter. Refer to Table 5.13 to select the correct DC reactor.
Table 5.13 DC Reactors for Harmonic Suppression (Manufacturer: Yaskawa Electric)
Drive Model DC Reactor Model DC Reactor Rating
2004 UZDA-B 5.4 A, 8 mH
2006 UZDA-B 5.4 A, 8 mH
4002 UZDA-B 3.2 A, 28 mH
4004 UZDA-B 3.2 A, 28 mH
