YASKAWA GA700 Series

Standards Compliance
5
5.3 UL Standards
YASKAWA SIEPC71061705H GA700 Series Technical Manual 253
■ Closed-Loop Crimp Terminals
To comply with UL standards on drive models 2257 to 2415 and 4208 to 4675, use UL-approved closed-loop
crimp terminals. Use the tools recommend by the terminal manufacturer to crimp the closed-loop crimp terminal.
Yaskawa recommends closed-loop crimp terminals from JST Mfg. Co., Ltd. and insulation caps from Tokyo DIP
Co., Ltd.
Make sure that you comply with local standards for correct wire gauges in the region where you will use the drive.
Contact Yaskawa or your nearest sales representative to order.
Refer to Table 5.15 and Table 5.16 to select crimp terminals as specified by drive model and wire gauge.
Note:
To comply with UL standards, use only insulated crimp terminals or crimp terminals with insulation tubing. Use UL-Listed, vinyl-
coated insulated copper wires for operation with a continuous maximum permitted temperature of 75 °C at 600 V.
Table 5.15 Closed-Loop Crimp Terminals and Insulation Caps: Three-Phase 200 V Class
Model
Recomm. Gauge (AWG, kcmil)
Terminal
Screw Size
Crimp
Terminal
Model
Crimping Tool
Insulation
Cap Model
R/L1
S/L2
T/L3
U/T1
V/T2
W/T3
-, +1 +3 Tool Model Die Jaw
2004 - 2021 - - - - 10 M4 R5.5-4 YA-4 AD-900 TP-005
2030, 2042 - - - - 8 M5 R8-5 YA-4 AD-901 TP-008
2056 - - - - 6 M6 R14-6 YA-4 AD-902 TP-014
2070 - 2110 - - - - 6 M6 R14-6 YA-4 AD-902 TP-014
2138 - - - - 4 M6 R22-6 YA-5 AD-953 TP-022
2169, 2211 - - - - 4 M8 R22-8 YA-5 AD-953 TP-022
2257
- - - - 3
M10
R38-10
YF-1
YET-150-1
TD-224, TD-
212
TP-038
- - - 1/0 × 2P - R60-10
TD-225, TD-
213
TP-060
2/0 × 2P 2/0 × 2P - - - 80-10
TD-227, TD-
214
TP-080
- - 4/0 × 2P - - R100-10
TD-228, TD-
214
TP-100
2313
- - - - 2
M10
R38-10
YF-1
YET-150-1
TD-224, TD-
212
TP-038
- - - 1/0 × 2P - R60-10
TD-225, TD-
213
TP-060
- 3/0 × 2P - - - 80-10
TD-227, TD-
214
TP-080
4/0 × 2P - - - - R100-10
TD-228, TD-
214
TP-100
- - 250 × 2P - - R150-10
TD-229, TD-
215
TP-150
2360
- - - - 1
M12
R60-12
YF-1
YET-300-1
TD-321, TD-
311
TP-060
- - - 3/0 × 2P - 80-12
TD-323, TD-
312
TP-080
250 × 2P 250 × 2P - - - R150-12
TD-325, TD-
313
TP-150
- - 350 × 2P - - R200-12
TD-327, TD-
314
TP-200
2415
- - - - 1
M12
R60-12
YF-1
YET-300-1
TD-321, TD-
311
TP-060
- - - 3/0 × 2P - 80-12
TD-323, TD-
312
TP-080
250 × 2P -
- - - R150-12
TD-325, TD-
313
TP-150
- 300 × 2P
- - 350 × 2P - - R200-12
TD-327, TD-
314
TP-200
