YASKAWA GA700 Series

7.3 List of Fault, Minor Fault, Alarm, and Error Codes
318 YASKAWA SIEPC71061705H GA700 Series Technical Manual
Display (Hex.) Name ALM LED Type Ref.
oFA03 (0104) - oFA06 (0107) Option Card Error Occurred at Option Port (CN5-A) Illuminated Fault 333, 333
oFA10 (0111)
oFA11 (0112)
Option Card Error Occurred at Option Port (CN5-A) Illuminated Fault 333, 333
oFA12 (0113) - oFA17 (0118) Option Card Connection Error (CN5-A) Illuminated Fault 333 - 334
oFA30 (0131) - oFA43 (013E) Communication Option Card Connection Error (CN5-A) Illuminated Fault 334 - 336
oFb00 (0201) Option Not Compatible with Port Illuminated Fault 336
oFb01 (0202) Option Fault/Connection Error Illuminated Fault 336
oFb02 (0203) Duplicate Options Illuminated Fault 336
oFb03 (0204) - oFb11 (0212) Option Card Error Occurred at Option Port (CN5-B) Illuminated Fault 336 - 337
oFb12 (0213) - oFb17 (0218) Option Card Connection Error (CN5-B) Illuminated Fault 337 - 337
oFC00 (0301) Option Not Compatible with Port Illuminated Fault 337
oFC01 (0302) Option Fault/Connection Error Illuminated Fault 337
oFC02 (0303) Duplicate Options Illuminated Fault 338
oFC03 (0304) - oFC11 (0312) Option Card Error Occurred at Option Port (CN5-C) Illuminated Fault 338 - 338
oFC12 (0313) - oFC17 (0318) Option Card Connection Error (CN5-C) Illuminated Fault 338 - 339
oFC50 (0351) - oFC55 (0356) Option Card Error Occurred at Option Port (CN5-C) Illuminated Fault 339 - 339
oH (0003) Heatsink Overheat Flashing Alarm 355
oH (0009) Heatsink Overheat Illuminated Fault 340
oH1 (000A) Heatsink Overheat Illuminated Fault 340
oH2 (0004) External Overheat (H1-XX=B) Flashing Alarm 355
oH3 (001D) Motor Overheat (PTC Input) Illuminated Fault 340
oH3 (0022) Motor Overheat (PTC Input) Flashing Alarm 355
oH4 (0020) Motor Overheat Fault (PTC Input) Illuminated Fault 341
oL1 (000B) Motor Overload Illuminated Fault 341
oL2 (000C) Drive Overload Illuminated Fault 342
oL3 (0005) Overtorque 1 Flashing Alarm 355
oL3 (000D) Overtorque Detection 1 Illuminated Fault 342
oL4 (0006) Overtorque 2 Flashing Alarm 356
oL4 (000E) Overtorque Detection 2 Illuminated Fault 342
oL5 (003D) Mechanical Weakening Detection 1 Flashing Alarm 356
oL5 (0044) Mechanical Weakening Detection 1 Illuminated Fault 342
oL7 (002B) High Slip Braking Overload Illuminated Fault 343
oPE01 Drive Capacity Setting Fault Flashing Parameter Setting Error 360
oPE02 Parameter Range Setting Error Flashing Parameter Setting Error 360
oPE03 Multi-Function Input Setting Err Flashing Parameter Setting Error 360
oPE05 Run Cmd/Freq Ref Source Sel Err Flashing Parameter Setting Error 361
oPE06 Control Method Selection Error Flashing Parameter Setting Error 362
oPE07 Analog Input Selection Error Flashing Parameter Setting Error 362
oPE08 Parameter Selection Error Flashing Parameter Setting Error 362
oPE09 PID Control Selection Fault Flashing Parameter Setting Error 363
oPE10 V/f Data Setting Error Flashing Parameter Setting Error 363
oPE11 Carrier Frequency Setting Error Flashing Parameter Setting Error 363
oPE13 Pulse Monitor Selection Error Flashing Parameter Setting Error 364
oPE15 Torque Control Setting Error Flashing Parameter Setting Error 364
oPE16 Energy Saving Constants Error Flashing Parameter Setting Error 364
oPE18 Online Tuning Param Setting Err Flashing Parameter Setting Error 364
oPE20 PG-F3 Setting Error Flashing Parameter Setting Error 364
