YASKAWA GA700 Series

Specifications
10
10.3 Model-Specific Specifications (200 V Class)
YASKAWA SIEPC71061705H GA700 Series Technical Manual 429
Model 2056 2070 2082 2110 2138
Input
Rated Input Current
(A)
HD1 (AC) 58.2 78.4 96 82 111
HD1 (DC) 71.3 96 118 100 136
ND1 (AC) 78.4 96 114 111 136
ND1 (DC) 96 117.6 139 136 166
Output
Rated Output
Capacity (kVA)
HD1
*3
17.9 22.9 28.6 33.5 43.8
ND1
*4
21.3 26.7 31.2 41.9 52.6
Rated Output
Current (A)
HD1 47 60 75 88 115
ND1 56 70 82 110 138
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds The permitted frequency of overload is one time each
10 minutes.
• ND: 110% of the rated output current for 60 seconds The permitted frequency of overload is one time each
10 minutes.
Note:
Derating can be necessary for applications that start and stop frequently.
Carrier Frequency
HD: 8 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
Maximum Output Voltage
Three-phase 200 V to 240 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• AOLV and EZOLV: 120 Hz
• CL-V/f, CLV, AOLV/PM, and CLV/PM: 400 Hz
• V/f, OLV, OLV/PM: 590 Hz
Measures for
Harmonics
DC reactor External options Standard internal characteristics
Braking Device Braking Transistor Standard internal characteristics
EMC Filter
EMC Filter
IEC61800-3, C3
Factory option
• Models 2xxxB: There is a category C3 EMC filter in the drive.
Power Supply
Rated Voltage, Rated Frequency
• Three-phase AC power supply 200 V to 240 Vat 50/60 Hz
• DC power supply 270 V to 340 V
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power (kVA)
HD1
24.2 32.6 39.9 34.1 46.1
ND1
32.6 39.9 47.4 46.1 56.5
*1 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output
current of the drive output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*3 The rated output capacity is calculated with a rated output voltage of 208 V.
*4 The rated output capacity is calculated with a rated output voltage of 220 V.
Table 10.4 Rating (200 V Class)
Model 2169 2211 2257 2313 2360 2415
Maximum Applicable Motor Output
(kW)
HD1
*1
37 45 55 75 90 110
ND1
*2
45 55 75 90 110 -
Maximum Applicable Motor Output
(HP)
HD1
*1
50 60 75 100 125 150
ND1
*2
60 75 100 125 150 -
Input
Rated Input
Current (A)
HD1 (AC) 136 164 200 271 324 394
HD1 (DC) 166 201 245 331 396 482
ND1 (AC) 164 200 271 324 394 -
ND1 (DC) 201 245 331 396 482 -
