YASKAWA GA700 Series

Specifications
10
10.6 Drive Derating
YASKAWA SIEPC71061705H GA700 Series Technical Manual 441
Model
Rated Current (A)
Heavy Duty Rating (HD1) Normal Duty Rating (ND1)
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz
2018
14.0 14.0 11.2 9.1 6.4 17.5 14.3 11 9.1 6.4
2021
17.5 17.5 14.7 12.6 9.9 21 17.8 15 12.5 9.9
2030
25.0 25.0 21.0 18.0 14.3 30 25.5 21 18.0 14.3
2042
33.0 33.0 25.7 20.2 13.3 42 33.9 26 20.4 13.7
2056
47.0 47.0 39.8 34.4 27.7 56 47.9 40 34.4 27.6
2070
60.0 60.0 52.0 46.0 38.5 70 61.0 52 46.0 38.5
2082
75.0 75.0 62.1 52.5 40.4 82 76.7 63 53.1 41.4
2110
88.0 88.0 72.9 61.6 47.5 110 93.5 77 66.0 52.3
2138
115.0 115.0 95.3 80.5 62.0 138 117.3 97 82.8 65.6
2169
145.0 128.5 98.8 78.9 - 169 132.3 95.7 71.2 -
2211
180.0 159.3 122.0 97.2 - 211 164.1 117.2 86.0 -
2257
215.0 189.8 144.5 114.3 - 257 197.2 137.3 97.4 -
2313
283.0 254.7 203.8 169.8 - 313 257.8 202.6 165.8 -
2360
346.0 302.9 225.3 173.6 - 360 294.8 230.0 186.8 -
2415
415.0 373.5 298.8 249.0 - 415 361.6 308.3 272.7 -
Table 10.15 Carrier Frequency and Rated Current Derating When A1-02 = 6 [AOLV/PM]
Model
Rated Current (A)
Heavy Duty Rating (HD1) Normal Duty Rating (ND1)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz
2004
3.2 3.2 3.1 3.0 2.8 2.6 3.5 3.1 2.8 2.4 2.1 1.7
2006
5.0 5.0 4.9 4.6 4.3 4.1 6.0 5.4 4.8 4.2 3.6 3.0
2010
8.0 8.0 7.7 6.7 5.8
4.8
9.6 8.6 7.7 6.7 5.8 4.8
2012
11.0 11.0 10.7 9.8 8.8
7.9
12.2 11.5 10.7 10.0 9.3 8.6
2018
14.0 14.0 13.3 11.2 9.1 6.9 17.5 15.4 13.3 11.2 9.1 6.9
2021
17.5 17.5 16.8 14.7 12.6 10.4 21.0 18.9 16.8 14.6 12.5 10.4
2030
25.0 25.0 24.0 21.0 18.0 15.0 30.0 27.0 24.0 21.0 18.0 15.0
2042
33.0 33.0 31.2 25.7 20.2 14.7 42.0 36.6 31.2 25.8 20.4 15.0
2056
47.0 47.0 45.2 39.8 34.4 29.0 56.0 50.6 45.2 39.8 34.4 29.0
2070
60.0 60.0 58.0 52.0 46.0 40.0 70.0 64.0 58.0 52.0 46.0 40.0
2082
75.0 75.0 71.8 62.1 52.5 42.9 82.0 81.4 72.0 62.6 53.1 43.7
2110
88.0 88.0 84.2 72.9 61.6 50.3 110.0 99.0 88.0 77.0 66.0 55.0
2138
115.0 115.0 110.1 95.3 80.5 65.7 138.0 124.2 110.4 96.6 82.8 69.0
2169
145.0 138.4 118.6 98.8 78.9 - 169.0 144.6 120.1 95.7 71.2 -
2211
180.0 171.7 146.9 122.0 97.2 - 211.0 179.7 148.5 117.2 86.0 -
2257
215.0 204.9 174.7 144.5 114.3 - 257.0 217.1 177.2 137.3 97.4 -
2313
283.0 271.7 237.7 203.8 169.8 - 313.0 276.2 239.4 202.6 165.8 -
2360
346.0 328.8 277.0 225.3 173.6 - 359.6 316.4 273.2 230.0 186.8 -
2415
415.0 398.4 348.6 298.8 249.0 - 415.0 379.4 343.9 308.3 272.7 -
