10.6 Drive Derating
442 YASKAWA SIEPC71061705H GA700 Series Technical Manual
■ 400 V Class
Table 10.16 Carrier Frequency and Rated Current Derating When A1-02 = 0, 1, 2, 3, 5, 7, 8 (< 460 V)
Model
Rated Current (A)
Heavy Duty Rating (HD1) Normal Duty Rating (ND1)
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz
4002
1.8 1.8 1.8 1.6 1.3 1.0 2.1 2.0 1.8 1.7 1.5 1.4
4004
3.4 3.4 3.4 2.9 2.3 1.7 4.1 3.8 3.4 3.1 2.8 2.4
4005
4.8 4.8 4.8 4.3 3.7 3.0 5.4 5.2 4.8 4.6 4.3 3.9
4007
5.5 5.5 5.5 4.9 4.1 3.2 7.1 6.5 5.5 4.8 4.0 3.2
4009
7.2 7.2 7.2 6.5 5.6 4.8 8.9 8.2 7.2 6.5 5.6 4.8
4012
9.2 9.2 9.2 8.1 6.8 5.4 11.9 10.8 9.2 8.1 6.7 5.4
4018
14.8 14.8 14.8 13.1 11.0 8.9 17.5 17.3 14.8 13.1 11.0 8.9
4023
18.0 18.0 18.0 15.9 13.4 10.8 23 21.5 18.3 16.2 13.6 11.0
4031
24.0 24.0 24.0 21.2 17.7 14.1 31 28.2 24.0 21.1 17.6 14.1
4038
31.0 31.0 31.0 27.5 23.0 18.6 38 36.3 31.0 27.5 23.0 18.6
4044
39.0 39.0 39.0 34.5 29.0 23.4 44 43.6 37.5 33.5 28.4 23.4
4060
45.0 45.0 45.0 39.1 31.8 24.4 60 53.7 44.9 39.1 31.7 24
4075
60.0 60.0 60.0 53.1 44.6 36.0 75 73.8 62.9 55.6 46.5 37
4089
75.0 75.0 75.0 66.4 55.7 45.0 89 88.8 75.8 67.2 56.4 46
4103
91.0 91.0 91.0 80.6 67.6 54.6 103 103.0 90.3 80.1 67.3 55
4140
112.0 112.0 91.8 78.4 - - 140 122.8 96.7 79 - -
4168
150.0 150.0 123.0 105.0 - - 168 150.5 124.4 107 - -
4208
180.0 180.0 147.6 126.0 - - 208 179.7 137.2 109 - -
4250
216.0 216.0 177.1 151.2 - - 250 221.8 179.4 151 - -
4296
260.0 260.0 213.2 182.0 - - 296 263.4 214.6 182 - -
4371
304.0 304.0 249.3 212.8 - - 371 327.2 261.6 218 - -
4389
371.0 371.0 304.2 259.7 - - 389 348 286.3 245 - -
4453
414.0 345.7 - - - - 453 349 - - - -
4568
453.0 378.3 - - - - 568 437 - - - -
4675
605.0 505.2 - - - - 675 529 - - - -
Table 10.17 Carrier Frequency and Rated Current Derating When A1-02 = 4 [AOLV] (< 460 V)
Model
Rated Current (A)
Heavy Duty Rating (HD1) Normal Duty Rating (ND1)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz
4002
1.8 1.8 1.3 1.0 0.6 2.1 1.8 1.6 1.4 1.2
4004
3.4 3.4 2.4 1.7 0.8 4.1 3.5 2.8 2.4 1.9
4005
4.8 4.8 3.8 3.0 2.1 5.4 4.9 4.3 3.9 3.5
4007
5.5 5.5 4.2 3.2 2.0 7.1 5.7 4.2 3.2 2.0
4009
7.2 7.2 5.8 4.8 3.5 8.9 7.4 5.8 4.8 3.5
4012
9.2 9.2 7.0 5.4 3.3 11.9 9.5 7.0 5.4 3.3
4018
14.8 14.8 11.4 8.9 5.7 17.5 15.2 11.4 8.9 5.7
4023
18.0 18.0 13.9 10.8 6.9 23 18.8 14.1 11.0 7.1
4031
24.0 24.0 18.4 14.1 8.8 31 24.7 18.3 14.1 8.8
4038
31.0 31.0 23.9 18.6 12.0 38 31.9 23.9 18.6 12.0
4044
39.0 39.0 30.1 23.4 15.0 44 38.5 29.5 23.4 15.8
4060
45.0 45.0 33.3 24.4 13.4 60 46.4 33.2 24.4 13.4
4075
60.0 60.0 46.3 36.0 23.1 75 64.7 48.4 37.5 23.8
