YASKAWA GA700 Series

Specifications
10
10.6 Drive Derating
YASKAWA SIEPC71061705H GA700 Series Technical Manual 443
Model
Rated Current (A)
Heavy Duty Rating (HD1) Normal Duty Rating (ND1)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz
4089
75.0 75.0 57.9 45.0 28.9 89 78.0 58.6 45.6 29.4
4103
91.0 91.0 70.2 54.6 35.1 103 92.8 69.9 54.6 35.5
4140
112.0 95.2 65.0 44.8 - 140 101.1 62.0 36 -
4168
150.0 127.5 87.0 60.0 - 168 128.7 89.5 63 -
4208
180.0 153.0 104.4 72.0 - 208 144.3 80.6 38 -
4250
216.0 183.6 125.3 86.4 - 250 186.5 123.0 81 -
4296
260.0 221.0 150.8 104.0 - 296 222.7 149.4 101 -
4371
304.0 258.4 176.3 121.6 - 371 272.5 174.0 108 -
4389
371.0 315.4 215.2 148.4 - 389 297 203.8 142 -
4453
414.0 259.8 - - - 453 219 - - -
4568
453.0 284.3 - - - 568 274 - - -
4675
605.0 379.6 - - - 675 345 - - -
Table 10.18 Carrier Frequency and Rated Current Derating When A1-02 = 6 [AOLV/ PM] (< 460 V)
Model
Rated Current (A)
Heavy Duty Rating (HD1) Normal Duty Rating (ND1)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz
4002
1.8 1.8 1.7 1.3 1.0 0.6 2.1 1.9 1.7 1.6 1.4 1.2
4004
3.4 3.4 3.2 2.4 1.7 1.0 4.1 3.7 3.3 2.8 2.4 2.0
4005
4.8 4.8 4.5 3.8 3.0 2.3 5.4 5.0 4.7 4.3 3.9 3.6
4007
5.5 5.5 5.2 4.2 3.2 2.3 7.1 6.1 5.2 4.2 3.2 2.3
4009
7.2 7.2 6.9 5.8 4.8 3.8 8.9 7.9 6.8 5.8 4.8 3.7
4012
9.2 9.2 8.7 7.0 5.4 3.8 11.9 10.3 8.6 7.0 5.4 3.8
4018
14.8 14.8 14.0 11.4 8.9 6.3 17.5 16.5 14.0 11.4 8.9 6.3
4023
18.0 18.0 17.0 13.9 10.8 7.7 23.4 20.4 17.3 14.1 11.0 7.8
4031
24.0 24.0 22.6 18.4 14.1 9.9 31.0 26.8 22.6 18.3 14.1 9.9
4038
31.0 31.0 29.2 23.9 18.6 13.3 38.0 34.5 29.2 23.9 18.6 13.3
4044
39.0 39.0 36.8 30.1 23.4 16.7 44.0 41.6 35.5 29.5 23.4 17.3
4060
45.0 45.0 42.1 33.3 24.4 15.6 59.6 50.8 42.0 33.2 24.4 15.6
4075
60.0 60.0 56.6 46.3 36.0 25.7 74.9 70.2 59.3 48.4 37.5 26.5
4089
75.0 75.0 70.7 57.9 45.0 32.1 89.2 84.5 71.5 58.6 45.6 32.7
4103
91.0 91.0 85.8 70.2 54.6 39.0 103.0 100.5 85.2 69.9 54.6 39.3
4140
112.0 105.3 85.1 65.0 44.8 - 140.0 114.1 88.1 62.0 36.0 -
4168
150.0 141.0 114.0 87.0 60.0 - 168.0 141.8 115.6 89.5 63.3 -
4208
180.0 169.2 136.8 104.4 72.0 - 208.0 165.5 123.1 80.6 38.1 -
4250
216.0 203.0 164.2 125.3 86.4 - 250.0 207.7 165.3 123.0 80.6 -
4296
260.0 244.4 197.6 150.8 104.0 - 296.0 247.1 198.3 149.4 100.6 -
4371
304.0 285.8 231.0 176.3 121.6 - 371.0 305.3 239.7 174.0 108.3 -
4389
371.0 348.7 282.0 215.2 148.4 - 389.0 327.5 265.7 203.8 142.0 -
4453
414.0 311.3 - - - - 453.0 296.7 - - - -
4568
453.0 340.7 - - - - 568.0 372.0 - - - -
4675
605.0 455.0 - - - - 675.0 455.0 - - - -
