11.5 b: Application
488 YASKAWA SIEPC71061705H GA700 Series Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
b5-56
(0BE2)
PID Feedback Monitor
Gain
Sets the gain for the monitor set in b5-55 [PID Feedback Monitor Selection].
1.00
(0.00 - 10.00)
680
b5-57
(11DD)
PID Feedback Monitor
Bias
Sets the bias for the monitor specified in b5-55 [PID Feedback Monitor Selection].
0.00
(-10.00 - +10.00)
680
b5-58
(1182)
RUN
PID Setpoints 2
Sets the PID setpoint when H1-xx = 3E or 3F [MFDI Function Select = PID Setpoint
Selection 1/2]. This value is a percentage of the maximum output frequency.
Note:
Parameter A1-02 [Control Method Selection] selects which parameter is the
maximum output frequency.
• A1-02 ≠ 8 [EZOLV]: E1-04 [Maximum Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.00%
(0.00 - 100.00%)
680
b5-59
(1183)
RUN
PID Setpoints 3
Sets the PID setpoint when H1-xx = 3E or 3F [MFDI Function Select = PID Setpoint
Selection 1/2]. This value is a percentage of the maximum output frequency.
Note:
Parameter A1-02 [Control Method Selection] selects which parameter is the
maximum output frequency.
• A1-02 ≠ 8 [EZOLV]: E1-04 [Maximum Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.00%
(0.00 - 100.00%)
680
b5-60
(1184)
RUN
PID Setpoints 4
Sets the PID setpoint when H1-xx = 3E or 3F [MFDI Function Select = PID Setpoint
Selection 1/2]. This value is a percentage of the maximum output frequency.
Note:
Parameter A1-02 [Control Method Selection] selects which parameter is the
maximum output frequency.
• A1-02 ≠ 8 [EZOLV]: E1-04 [Maximum Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.00%
(0.00 - 100.00%)
680
b5-61
(119A)
PID Trim Mode Lower
Limit Sel
Sets the function that adjusts the PID output in relation to the frequency reference.
0 : Disabled
1 : Enabled
0
(0, 1)
681
b5-62
(119B)
PID Trim Mode Lower
Limit Value
Sets the PID Trim Mode Lower Limit Value as a percentage of the maximum output
frequency.
Note:
Parameter A1-02 [Control Method Selection] selects which parameter is the
maximum output frequency.
• A1-02 ≠ 8 [EZOLV]: E1-04 [Maximum Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.00%
(0.00 - 100.00%)
681
b5-63
(119C)
PID Differential FB
Monitor Sel
Selects the monitor (Ux-xx) used as the PID Differential Feedback. Set the x-xx part of
the Ux-xx [Monitor].
000
(000 - 999)
681
b5-64
(119D)
PID Differential FB
Monitor Gain
Sets the gain for the monitor specified in b5-63 [PID Differential FB Monitor Sel].
1.00
(0.00 - 10.00)
681
b5-65
(119F)
PID Differential FB
Monitor Bias
Sets the bias for the monitor specified in b5-63 [PID Differential FB Monitor Sel].
0.00
(-10.00 - +10.00)
682
b5-66
(11DE)
PID Feedback Monitor
Level
Sets the signal level for the monitor specified in b5-55 [PID Feedback Monitor
Selection].
0 : Absolute
1 : Bi-directional (+/-)
0
(0, 1)
682
b5-67
(11DF)
PID Differential FB
Monitor Lvl
Sets the signal level for the monitor specified in b5-63 [PID Differential FB Monitor
Sel].
0 : Absolute
1 : Bi-directional (+/-)
0
(0, 1)
682
b5-89
(0B89)
RUN
Sleep Method Selection
Sets sleep and wake up operation when using PID.
0 : Standard
1 : EZ Sleep/Wake-up
0
(0, 1)
682
b5-90
(0B90)
EZ Sleep Unit
Sets the measurement units for b5-91 [EZ Sleep Minimum Speed] and b5-92 [EZ Sleep
Level].
0 : 0.1Hz units
1 : rev/min
0
(0, 1)
682
b5-91
(0B91)
RUN
EZ Sleep Minimum
Speed
Sets the minimum speed for the EZ Sleep/Wakeup function. This parameter uses the
largest value from b5-91, b5-34 [PID Output Lower Limit Level], and d2-02 [Frequency
Reference Lower Limit].
0.0 Hz or 0 min
-1
(r/min)
(0.0 to 590.0 Hz or 0 to
35400 min
-1
(r/min))
682
