11.10 H: Terminal Functions
528 YASKAWA SIEPC71061705H GA700 Series Technical Manual
Setting Value Function Description Ref.
116 !Motor 2 Selection
Switches between motor 1 or motor 2. Switch the motor while the motor is stopped.
ON : Selects motor 1
OFF : Selects motor 2
821
118 !Timer Function
Sets the command to start the timer function. Use this setting with H2-xx = 112 [!Timer Output].
821
119 !PID Disable
Sets the command to disable PID control with an external input when b5-01 = 1 to 8 [PID Function Setting =
Enabled].
ON : PID control enabled
OFF : PID control disabled
821
11A !Accel/Decel Time
Selection 2
Set this function and H1-xx = 107 [!Accel/Decel Time Selection 1] together. Sets the drive to use C1-01 to C1-08
[Acceleration/Deceleration Times 1 to 4].
821
11B !Programming Lockout
Sets the command to prevent parameter changes when the terminal is OFF. You can continue to view parameter
setting values when the terminal is ON [Parameter Write Prohibit].
ON : Parameter Write Prohibit
OFF : Programming Lockout
821
11E !Reference Sample Hold
Samples the analog frequency reference input to the terminals A1, A2, or A3, and continues operation at the
sampled frequency.
821
130 !PID Integrator Reset
Sets the command to reset and hold the PID control integral to 0 when the terminal deactivates.
821
131 !PID Integrator Hold
Sets the command to hold the integral value of the PID control while the terminal deactivates.
821
132 !Multi-Step Speed
Reference 4
Uses a combination of multi-step speed references 1, 2 and 3 (N.C.) to switch d1-09 to d1-16 [Reference 9 to 16].
821
134 !PID Soft Starter Disable
Sets the PID soft starter function.
ON : Enabled
OFF : Disable
821
135 !PID Input (Error) Invert
Sets the command to turn the terminal ON and OFF to switch the PID input level (polarity).
821
13E !PID Setpoint Selection
1
Set this function and H1-xx = 13F [!PID Setpoint Selection 2] together. Sets the function to use the PID setpoint
set in b5-58 to b5-60 [PID setpoint2 to 4].
821
13F !PID Setpoint Selection
2
Set this function and H1-xx = 13E [!PID Setpoint Selection 1] together. Sets the function to use the PID setpoint
set in b5-58 to b5-60 [PID setpoint2 to 4].
821
144 !Add Offset Frequency 1
(d7-01)
Sets the function to add the offset frequency set in d7-01 to the frequency reference when the terminal deactivates.
821
145 !Add Offset Frequency 2
(d7-02)
Sets the function to add the offset frequency set in d7-02 to the frequency reference when the terminal deactivates.
821
146 !Add Offset Frequency 3
(d7-03)
Sets the function to add the offset frequency set in d7-03 to the frequency reference when the terminal deactivates.
821
147 !Node Setup (CANopen)
Sets the function in CANopen communications to start the Node Setup function to set the drive node address from
the host controller.
821
160 !DC Injection Braking
Command
Sets the command to use DC Injection Braking to stop the motor.
Note:
When A1-02 = 8 [Control Method Selection = EZ Vector Control], this function is available if you use a PM
motor.
821
161 !Speed Search from
Fmax
Sets the function to use an external reference to start speed search although b3-01 = 0 [Speed Search Selection at
Start = Disabled] to not allow speed search at start.
Note:
The drive will detect oPE03 [Multi-Function Input Setting Err] when H1-xx = 161 [!Speed Search from
Fmax] and H1-xx = 162 [!Speed Search from Fref] are set at the same time.
821
162 !Speed Search from Fref
Sets the function to use an external reference to start speed search although b3-01 = 0 [Speed Search Selection at
Start = Disabled] to not allow speed search at start.
Note:
The drive will detect oPE03 [Multi-Function Input Setting Err] when H1-xx = 161 [!Speed Search from
Fmax] and H1-xx = 162 [!Speed Search from Fref] are set at the same time.
821
