11.10 H: Terminal Functions
YASKAWA SIEPC71061705H GA700 Series Technical Manual 531
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H2-34
(159C)
Comparator 2 Filter
Time
Sets the time constant that is applied to the primary delay filter used for the analog
output of the monitor selected with H2-26 [Comparator 2 Monitor Selection].
0.0s
(0.0 - 10.0 s)
828
H2-35
(159D)
Comparator2 Protection
Selection
Sets drive operation when it detects CP2 [Comparator2 Limit Fault].
0 : Ramp to Stop
1 : Coast to Stop
2 : Fast Stop (Use C1-09)
3 : Alarm Only
4 : Digital Output Only
4
(0 - 4)
828
H2-36
(159E)
Comparator 1 Ineffective
Time
Sets the length of time that CP1 [Comparator1 Limit Fault] is disabled.
0.0 s
(0.0 - 1000.0 s)
828
H2-37
(159F)
Comparator 2 Ineffective
Time
Sets the length of time that CP2 [Comparator2 Limit Fault] is disabled.
0.0 s
(0.0 - 1000.0 s)
828
H2-40
(0B58)
Mbus Reg 15E0h bit0
Output Func
Sets the MFDO for bit 0 of MEMOBUS register 15E0 (Hex.).
F
(0 - 1FF)
828
H2-41
(0B59)
Mbus Reg 15E0h bit1
Output Func
Sets the MFDO for bit 1 of MEMOBUS register 15E0 (Hex.).
F
(0 - 1FF)
829
H2-42
(0B5A)
Mbus Reg 15E0h bit2
Output Func
Sets the MFDO for bit 2 of MEMOBUS register 15E0 (Hex.).
F
(0 - 1FF)
829
H2-60
(1B46)
Expert
Term M1-M2 Secondary
Function
Sets the second function for terminal M1-M2. Outputs the logical calculation results of
the terminals assigned to functions by H2-01 [Term M1-M2 Function Selection].
F
(0 - FF)
829
H2-61
(1B47)
Expert
Terminal M1-M2
Logical Operation
Sets the logical operation for the functions set in H2-01 [Term M1-M2 Function
Selection] and H2-60 [Term M1-M2 Secondary Function].
0
(0 - 8)
829
H2-62
(1B48)
Expert
Terminal M1-M2 Delay
Time
Sets the minimum on time used to output the logical calculation results from terminal
M1-M2.
0.1 s
(0.0 - 25.0 s)
829
H2-63
(1B49)
Expert
Term M3-M4 Secondary
Function
Sets the second function for terminal M3-M4. Outputs the logical calculation results of
the terminals assigned to functions by H2-02 [Term M3-M4 Function Selection].
F
(0 - FF)
829
H2-64
(1B4A)
Expert
Terminal M3-M4
Logical Operation
Sets the logical operation for the functions set in H2-02 [Term M3-M4 Function
Selection] and H2-63 [Term M3-M4 Secondary Function].
0
(0 - 8)
829
H2-65
(1B4B)
Expert
Terminal M3-M4 Delay
Time
Sets the minimum on time used to output the logical calculation results from terminal
M3-M4.
0.1 s
(0.0 - 25.0 s)
830
H2-66
(1B4C)
Expert
Term M5-M6 Secondary
Function
Sets the second function for terminal M5-M6. Outputs the logical calculation results of
the terminals assigned to functions by H2-03 [Terminal M5-M6 Function Select].
F
(0 - FF)
830
H2-67
(1B4D)
Expert
Terminal M5-M6
Logical Operation
Sets the logical operation for the functions set in H2-03 [Term M5-M6 Function
Selection] and H2-66 [Term M5-M6 Secondary Function].
0
(0 - 8)
830
H2-68
(1B4E)
Expert
Terminal M5-M6 Delay
Time
Sets the minimum on time used to output the logical calculation results from terminal
M5-M6.
0.1 s
(0.0 - 25.0 s)
830
