12.11 o: Keypad-Related Settings
YASKAWA SIEPC71061705H GA700 Series Technical Manual 957
Item Specification
Line break code <CR><LF>
Separating character [ , ] (Commas)
Header rows First Row: Drive information including the drive model, software version, control method, and sampling time
Second Row: Log data information including the monitor number, number decimal points, and unit code
■ Log File Configuration
The [Log_Files] folder is created in the root directory of the microSD memory card. This is where the log data is
stored as CSV files. Log data files are created in this configuration. The number of rows changes when the
number of selected monitors change.
First Row Drive information
Second Row Log data information
Third Row Log data 1
: Log data 2
: Log data 3
: :
Last Row Log data n
First Row: Drive Information
This example shows the data text strings and data generated for the first row of log data.
Example of generated data: 00,0012,160107111230,GA700,VSAA01010,2,62,1000,000001
No. Item
Number
of
Charac
ters
Example Description
1 Attribute 2 00 [00] shows that the record is a drive information record.
2 File number 4 0012 Generates the [xxx] part (a 3-digit decimal number) of the [GLOG0xxx.csv] filename of the log data
in hexadecimal format.
Example filename of [GLOG0018.csv]: 018 (Dec.) = 0012 (Hex.)
3 Time stamp
*1
12 160107111230 Data log data was retrieved (YYMMDDHHMMSS)
･ Date: 20YY/MM/DD
･ Time in 24-hour format: HH:MM:SS
Example data of [160107111230]: 11:12:30 on January 7, 2016
4 Model 5 GA700 Drive model information
5 Software number 9 VSAA01010 Drive software number
6 Control Method Selection 1 2 Setting value (Hex.) of A1-02 [Control Method Selection]
7 Drive capacity 2 62 Setting value (Hex.) of o2-04 [Drive Model (KVA) Selection]
8 Sampling time 5
(Maximum)
1000 Setting value (Dec.) of o5-02 [Log Sampling Interval]
Unit: ms
9 Row number 6 000001 Row number (Hex.) in the data log file
*1 If you do not set the time in the keypad, the text string of [000000000000] is generated to show the time.
Second Row: Log Data Information
This example shows the data text strings and data generated for the second row of log data.
Example of generated data:
01,0012,160107111230,0101,0201,0102,0201,0103,0206,0107,0005,0108,0209,0000,0000,0000,0000,0000,0
000,0000,0000,0000,0000,0000,0000,0000,0000,000002
No. Item
Number of
Characters
Description
1 Attribute 2 [01] shows that the record is a log data information record.
2 File number 4 Generates the [xxx] part (a 3-digit decimal number) of the [GLOG0xxx.csv] filename of the log data in hexadecimal
format.
3 Time stamp 12 Data log data was retrieved (YYMMDDHHMMSS)
4 Monitor Number 1
*1
4 Monitor number selected by o5-03 [Log Monitor Data 1]
Example: 0101 (Dec.) for U1-01
