AT-GS900M Series CLI Reference

Section III: Layer 2 Switching 207

Example

The following example displays the settings of the IP address on the

switch:

Manager > show ip

DCHP client Displays whether the DHCP client is Enabled or

Disabled.

DHCP server Displays the IPv4 address of the DHCP server. This

is displayed only when the IPv4 address was

assigned to the switch using the DHCP server.

Directed

broadcast

Displays whether the switch responds to the

directed broadcast ping.

Table 28. SHOW IP Command (Continued)

Field Description
