1 Smaller Cyclone IV E devices or package options (E144 and F256 packages) do not
have the
MSEL[3] pin. The AS Fast POR configuration scheme at 3.0- or 2.5-V
configuration voltage standard and the AP configuration scheme are not supported in
Cyclone IV E devices without the
MSEL[3] pin. To configure these devices with other
supported configuration schemes, select
MSEL[2..0] pins according to the MSEL
settings in Table 8–5.
JTAG-based configuration
(2)
(3)(3) (3)(3)
——
Notes to Table 8–4:
(1) Configuration voltage standard applied to the V
CCIO
supply of the bank in which the configuration pins reside.
(2) JTAG-based configuration takes precedence over other configuration schemes, which means the
MSEL pin settings are ignored.
(3) Do not leave the
MSEL pins floating. Connect them to V
CCA
or GND. These pins support the non-JTAG configuration scheme used in production.
Altera recommends connecting the
MSEL pins to GND if your device is only using JTAG configuration.
Table 8–4. Configuration Schemes for Cyclone IV GX Devices (EP4CGX30 [only for F484 package], EP4CGX50,
EP4CGX75, EP4CGX110, and EP4CGX150) (Part 2 of 2)
Configuration Scheme MSEL3 MSEL2 MSEL1 MSEL0 POR Delay Configuration Voltage Standard (V)
(1)
Table 8–5. Configuration Schemes for Cyclone IV E Devices
Configuration Scheme MSEL3 MSEL2 MSEL1 MSEL0 POR Delay Configuration Voltage Standard (V)
(1)
AS
1 1 0 1 Fast 3.3
0 1 0 0 Fast 3.0, 2.5
0010Standard 3.3
0 0 1 1 Standard 3.0, 2.5
AP
0 1 0 1 Fast 3.3
0 1 1 0 Fast 1.8
0111Standard 3.3
1 0 1 1 Standard 3.0, 2.5
1000Standard 1.8
PS
1 1 0 0 Fast 3.3, 3.0, 2.5
0 0 0 0 Standard 3.3, 3.0, 2.5
FPP
1 1 1 0 Fast 3.3, 3.0, 2.5
1 1 1 1 Fast 1.8, 1.5
JTAG-based configuration
(2)
(3)(3)(3)(3)
——
Notes to Table 8–5:
(1) Configuration voltage standard applied to the V
CCIO
supply of the bank in which the configuration pins reside.
(2) JTAG-based configuration takes precedence over other configuration schemes, which means the
MSEL pin settings are ignored.
(3) Do not leave the
MSEL pins floating. Connect them to V
CCA
or GND. These pins support the non-JTAG configuration scheme used in production.
Altera recommends connecting the
MSEL pins to GND if your device is only using JTAG configuration.
