8–12 Chapter 8: Configuration and Remote System Upgrades in Cyclone IV Devices
Configuration
Cyclone IV Device Handbook, May 2013 Altera Corporation
Volume 1
devices. The internal oscillator is designed to ensure that its maximum frequency is
guaranteed to meet EPCS device specifications. Cyclone IV devices offer the option to
select
CLKUSR
as the external clock source for
DCLK
. You can change the clock source
option in the Quartus II software in the Configuration tab of the Device and Pin
Options dialog box.
1 EPCS1 does not support Cyclone IV devices because of its insufficient memory
capacity.
In configuration mode, the Cyclone IV device enables the serial configuration device
by driving the
nCSO
output pin low, which connects to the
nCS
pin of the configuration
device. The Cyclone IV device uses the
DCLK
and
DATA[1]
pins to send operation
commands and read address signals to the serial configuration device. The
configuration device provides data on its
DATA
pin, which connects to the
DATA[0]
input of the Cyclone IV device.
All AS configuration pins (
DATA[0]
,
DCLK
,
nCSO
, and
DATA[1]
) have weak internal pull-
up resistors that are always active. After configuration, these pins are set as input tri-
stated and are driven high by the weak internal pull-up resistors.
The timing parameters for AS mode are not listed here because the t
CF2CD
, t
CF2ST0
, t
CFG
,
t
STATUS
, t
CF2ST1
, and t
CD2UM
timing parameters are identical to the timing parameters
for PS mode shown in Table 8–12 on page 8–36.
Table 8–6. AS DCLK Output Frequency
Oscillator Minimum Typical Maximum Unit
40 MHz 20 30 40 MHz
