Switching Characteristics
December 2016 Altera Corporation Cyclone IV Device Handbook,
Volume 3
t
DLOCK
Time required to lock dynamically (after switchover,
reconfiguring any non-post-scale counters/delays or
areset is deasserted)
—— 1 ms
t
OUTJITTER_PERIOD_DEDCLK
(6)
Dedicated clock output period jitter
F
OUT
 100 MHz
— — 300 ps
F
OUT
< 100 MHz — — 30 mUI
t
OUTJITTER_CCJ_DEDCLK
(6)
Dedicated clock output cycle-to-cycle jitter
F
OUT
 100 MHz
— — 300 ps
F
OUT
< 100 MHz — — 30 mUI
t
OUTJITTER_PERIOD_IO
(6)
Regular I/O period jitter
F
OUT
 100 MHz
— — 650 ps
F
OUT
< 100 MHz — — 75 mUI
t
OUTJITTER_CCJ_IO
(6)
Regular I/O cycle-to-cycle jitter
F
OUT
 100 MHz
— — 650 ps
F
OUT
< 100 MHz — — 75 mUI
t
PLL_PSERR
Accuracy of PLL phase shift — — ±50 ps
t
ARESET
Minimum pulse width on areset signal. 10 — — ns
t
CONFIGPLL
Time required to reconfigure scan chains for PLLs — 3.5
(7)
—
SCANCLK
cycles
f
SCANCLK
scanclk frequency — — 100 MHz
t
CASC_OUTJITTER_PERIOD_DEDCLK
(8), (9)
Period jitter for dedicated clock output in cascaded
PLLs (F
OUT
 100 MHz)
— — 425 ps
Period jitter for dedicated clock output in cascaded
PLLs (F
OUT
 100 MHz)
— — 42.5 mUI
Notes to Table 1–25:
(1) This table is applicable for general purpose PLLs and multipurpose PLLs.
(2) You must connect V
CCD_PLL
to V
CCINT
through the decoupling capacitor and ferrite bead.
(3) This parameter is limited in the Quartus II software by the I/O maximum frequency. The maximum I/O frequency is different for each I/O
standard.
(4) The V
CO
frequency reported by the Quartus II software in the PLL Summary section of the compilation report takes into consideration the V
CO
post-scale counter K value. Therefore, if the counter K has a value of 2, the frequency reported can be lower than the f
VCO
specification.
(5) A high input jitter directly affects the PLL output jitter. To have low PLL output clock jitter, you must provide a clean clock source that is less
than 200 ps.
(6) Peak-to-peak jitter with a probability level of 10
–12
(14 sigma, 99.99999999974404% confidence level). The output jitter specification applies
to the intrinsic jitter of the PLL when an input jitter of 30 ps is applied.
(7) With 100-MHz
scanclk frequency.
(8) The cascaded PLLs specification is applicable only with the following conditions:
■ Upstream PLL—0.59 MHz  Upstream PLL bandwidth < 1 MHz
■ Downstream PLL—Downstream PLL bandwidth > 2 MHz
(9) PLL cascading is not supported for transceiver applications.
Table 1–25. PLL Specifications for Cyclone IV Devices
(1), (2)
(Part 2 of 2)
Symbol Parameter Min Typ Max Unit
