3-46 PN: 10580-00343 Rev. H S820E UG
3-7 Measurement Setup Cable and Antenna Measurements
In Figure 3-28, Marker M5 is set for Tracking a Valley between markers M1
and M2. Marker M6 is Tracking a Valley between markers M3 and M4. The
table of markers (below the sweep window in Figure 3-28) shows only
4 markers, but the table can be expanded or reduced by tapping on the table.
Figure 3-28. Tracking A Valley Between Markers
