2-20 PN: 10580-00343 Rev. H S820E UG
2-5 Touchscreen Display Overview Instrument Overview
2. Battery icon. Press to view battery and charge status. Press Esc to close.
The first row shows the icon when the Site Master is plugged into the AC
adapter or car charger and the battery is not detected.
The second row shows the battery icon when the battery is fully charged
and the Site Master is plugged into the AC adaptor or car charger.
The third row of battery icons show the charge level from 100 % to 2 %
when the Site Master is running on battery power.
The lightning bolt is displayed when the Site Master is charging from an
AC adapter or the car charger and the battery is not fully charged yet.
The fourth row shows the battery level from 2 % to 100 % under this
condition.
An exclamation point is displayed when the battery charging has paused,
either due to the ambient temperature being too high or too low to safely
charge the battery, or due to a fault in the battery. The exact cause is
displayed in the battery dialog under charge status.
The last row shows the battery level from 2 % to 100 % under this
condition. The battery will resume charging automatically as soon as the
pause conditions have changed.
Refer to Chapter 12, “Battery Replacement” for additional information.
3. GPS icon. Press to view the current GPS information (Figure 2-9)
obtained from an external USB-based GPS module. The icon indicates
the status of the GPS module and location fix. After capturing a good fix,
location data are saved with measurements (Figure 2-10) and screen
captures.
GPS status icon states:
a. GPS module (H/W) is not connected. Connect an Anritsu approved
GPS module.
b. H/W connected without a current location fix. Module attempts to
establish a location fix during this state.
c. H/W connected with a current location fix.
d. H/W not connected, instrument using last saved location fix. Pressing
Reset button places GPS in state “a.”
e. H/W connected, GPS fix lost, using last saved location fix. Pressing
Reset button places GPS in state “c.”
Figure 2-8. Status Tool Bar Icons (Continued)
