Installing under Windows
AX3000 Models 90 - User's Manual 135
These parameters are:
- Encryption: the supported encryption protocols are:
- Basic Level: default encryption protocol of Metaframe.
- RC5: strongest encryption protocol (with different key lengths)
- Connection Name: this character string identifies the AX3000 within the
Windows Operating System (see CLIENTNAME environment variable).
The default value is the thin client name (see Chapter 3.1.1).
- Optimized Screen Refresh: smooth video playback especially for flash
type content (ie Youtube).
- <Ctrl><Alt><Del>: the two modes for this keystroke are:
- Local: the keystroke is handled by the AX3000 and is used for
shutdown the thin client (see Chapter 4.8)
- Remote: the keystroke is handled by the Windows server (for
example opening the task manager).
-
<Scroll Lock> & <Pause
>:
enable or disable these two keys 5.2.8 - Redirected Resources
The redirected resources mechanism allows one or more local resources to be
'published' to the Windows server. These resources are available only for the
thin client's user. They are created on the Windows server when the connection
is established and removed when the session is disconnected.
The following local resources are supported:
- Printers: before being redirected each printer must be declared at the
'physical connection port' level. See first sub-section a) then c).
- COM/LPT ports before being redirected each port must be declared at
the physical port level. See first sub-section b) then c) and d).
- Mass storage devices: see sub-section c).
- Smartcard readers: see sub-section c)
- Audio: see sub-section c)
a) Declaring a Redirected Printer
At the RDP/ICA connection time a redirected printer will be automatically added
to the Windows spooler. It will be removed when the session disconnects.
Before being redirected an RDP/ICA printer must be declared at the 'physical
connection port' level. The available ports are USB logical ports and network
