Axel AX3000 User Manual

Installing under OS/400
174 AX3000 Models 90 - User's Manual
a) Start and Stop Sequence
Enable the transparent mode and select the start and stop sequence (default
value: @%@)
b) Operating Mode Rules
The transparent mode is driven by the following rules:
 For a screen session, enable the transparent mode by sending the
transparent sequence (@%@) followed by the port number:
0: default port.
1 to 3: native auxiliary ports (Aux1, Aux2 and parallel)
4 to 5: network printer (Net1 and Net2).
6 to 9: USB logical ports (Usb1, Usb2, Usb3 and Usb4).
 For a printer session, send only the transparent sequence to enable the
transparent mode.
 In both case, the transparent mode is disabled when the transparent
sequence is sent a second time.
 The character remapping is based on PC850 ASCII table (as with the
ASCII to EBCDIC function).
c) Character or Hexadecimal Mode
The two transparent modes are:
- Character Mode: the dataflow can contain both ASCII characters and
hexadecimal ASCII code. The hexadecimal code must began by a / and
the ASCII code is encoded by two digit (between 0 and F).
Example: Esc AB <RC> is \1BAB\0D
- Hexadecimal Mode: the dataflow contains only hexadecimal codes
(encoded by two digits).
Example: Esc AB <RC> is 1B41420D
d) Examples
With the following examples the start and stop sequence is @%@
