Interactive Set-Up

44 AX3000 Models 90 - User's Manual

Note: see previous protected access mode for WPA / WPA2 protocols

"Protected Access" is "802.1X"

Authentication Mode

Data Encryption

Password

Certificate

LEAP

WEP

required

---

PEAP (MS-CHAP v2)

WEP

required

optional

EAP-TLS

WEP

---

required

c) Advanced Settings

Within the "Wireless Parameters" dialog box, click "Enhanced Parameters":
